Texnik parametr
|
Model NO. |
P1.953 |
P2.604 |
P2.976 |
P3.91 |
P4.81 |
|
Piksel balandligi |
1,95 mm |
2,6 mm |
2,9 mm |
3,91 mm |
4,81 mm |
|
LED turi |
SMD1415 |
SMD415 |
SMD1921 |
SMD1921 |
SMD2525 |
|
Modullar orasidagi tekislik |
0,1 mm dan kam yoki unga teng |
0,1 mm dan kam yoki unga teng |
0,1 mm dan kam yoki unga teng |
0,1 mm dan kam yoki unga teng |
0,1 mm dan kam yoki unga teng |
|
Piksel konfiguratsiyasi |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
|
Modul hajmi (W*H) |
250 * 250 mm |
250 * 250 mm |
250 * 250 mm |
250 * 250 mm |
250 * 250 mm |
|
Modul ruxsati (W*H) |
128 * 128 mm |
96 * 96 mm |
84 * 84 mm |
64 * 64 mm |
52 * 52 mm |
|
Shkaf hajmi (W*Y*D) |
500 * 1000 * 75 mm |
500 * 1000 * 75 mm |
500 * 1000 * 75 mm |
500 * 1000 * 75 mm |
500 * 1000 * 75 mm |
|
Vazirlar Mahkamasi qarori (W*H) |
256 * 512 mm |
192*384 mm |
168 * 336 mm |
128 * 256 mm |
104 * 208 mm |
|
Shkafning og'irligi |
14,5 kg / dona |
14,5 kg / dona |
14,5 kg / dona |
14,5 kg / dona |
14,5 kg / dona |
|
Zichlik |
262144 nuqta/m² |
147456 nuqta/m² |
112896 nuqta/m² |
65400 nuqta/m² |
43264 nuqta/m² |
|
TUSHUNARLI |
2153 |
2153 |
2153 |
2153 |
2153 |
|
Skanerlash |
32S |
32S |
21S |
16S |
13S |
|
Eng yaxshi ko'rish masofasi |
>1.9m |
>2.6m |
>3m |
>4m |
>5m |
|
Eng yaxshi ko'rish burchagi |
160 daraja / 120 daraja |
160 daraja / 120 daraja |
160 daraja / 120 daraja |
160 daraja / 120 daraja |
160 daraja / 120 daraja |
|
Yorqinlik |
5500-6000cd/m² |
5500-6000cd/m² |
6000-6500cd/m² |
6000-6500cd/m² |
6500-7000cd/m² |
|
Ish kuchlanishi |
AC:110-240V 50~60Hz |
AC:110-240V 50~60Hz |
AC:110-240 V 50~60Hz |
AC:110-240V 50~60Hz |
AC:110-240V 50~60Hz |
|
Maksimal quvvat |
600 Vt/m² dan kam yoki unga teng |
600 Vt/m² dan kam yoki unga teng |
600 Vt/m² dan kam yoki unga teng |
600 Vt/m² dan kam yoki unga teng |
600 Vt/m² dan kam yoki unga teng |
|
O'rtacha quvvat sarfi |
100W/m² |
200W/m² |
200W/m² |
200W/m² |
200W/m² |
|
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
~300W / m² |
|
|
Ekran haroratining ko'tarilishi (ishlash holati) |
5 darajadan kamroq yoki unga teng |
5 darajadan kamroq yoki unga teng |
5 darajadan kamroq yoki unga teng |
5 darajadan kamroq yoki unga teng |
5 darajadan kamroq yoki unga teng |
|
Atrof-muhit haroratining ishlashi / darajasi |
-10 daraja ~60 daraja |
-10 daraja ~60 daraja |
-10 daraja ~60 daraja |
-10 daraja ~60 daraja |
-10 daraja ~60 daraja |
|
Ishlash harorati |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
10% ~ 90% RH |
|
Kondensatsiya yo'q |
Kondensatsiya yo'q |
Kondensatsiya yo'q |
Kondensatsiya yo'q |
Kondensatsiya yo'q |
|
|
Ekran rangi harorati |
2000K~9500K |
2000K~9500K |
2000K~9500K |
6500K~9500K |
7000K~10000K |
|
Haydash usuli |
1/32 skanerlash |
1/32 skanerlash |
1/32 skanerlash |
1/16 skanerlash |
1/16 skanerlash |
|
Kulrang shkala |
16 bit |
16 bit |
16 bit |
16 bit |
16 bit |
|
Yangilash chastotasi |
3840 Gts dan katta yoki unga teng |
3840 Gts dan katta yoki unga teng |
3840 Gts dan katta yoki unga teng |
3840 Gts dan katta yoki unga teng |
3840 Gts dan katta yoki unga teng |
|
IP darajasi |
Old: IP68 |
Old: IP68 |
Old: IP68 |
Old: IP68 |
Old: IP68 |
|
Orqaga: IP66 |
Orqaga: IP66 |
Orqaga: IP66 |
Orqaga: IP66 |
Orqaga: IP66 |
|
|
Doimiy ish vaqti |
7×24 soatdan katta yoki unga teng |
7×24 soatdan katta yoki unga teng |
7×24 soatdan katta yoki unga teng |
7×24 soatdan katta yoki unga teng |
7×24 soatdan katta yoki unga teng |
|
Muddat |
100,000soat |
100,000soat |
100,000soat |
100,000soat |
100,000soat |
|
O'rnatish usuli |
Orqa ramkani o'rnatish / ko'tarish / ichki yoyni o'rnatish |
||||
|
Pikselni tuzatish |
Nuqtama-nuqta nashrida va xromatiklikni tuzatish bilan jihozlangan |
||||
|
Boshqarish rejimi |
Sinxronizatsiya nazorati |
||||
|
Nazorat masofasi |
Super beshta ikki simli tarmoq kabeli, optik tolali uzatish yordamida 100 metrdan ortiq |
||||
|
Dastur interfeysi |
Windows XP /7/8/10 IOS |
||||
|
Signal kiritish |
HDMI, DVI, VGA, USB, LAN (kengaytirilgan interfeys) |
||||
|
Shkaf materiallari |
Suv o'tkazmaydigan quyma alyuminiy |
||||
|
Power Con |
Neut rick Kabel bilan quvvat ulagichi |
||||
|
Eter Con |
Neut rick Kabel bilan quvvat ulanishi |
||||
|
Ta'mirlash usuli |
Ikki tomonlama xizmat, old texnik xizmat ko'rsatish va orqaga xizmat ko'rsatish |
||||
|
Kafolat muddati |
3 yil kafolat muddati va bepul umr bo'yi texnik yordam |
||||
Xususiyatlari
1.Yupqa va engil quti dizayni yuk tashish xarajatlarini tejaydi
2.Qattiq ulanish dizayni, o'rnatish va olib tashlash oson
3. Old va orqa parvarishlash mumkin, 500 mm dan 500 x 1000 mm gacha bo'lgan shkaf o'lchamlari mavjud.
4.Indoor displey ekrani dizayni, yuqori yorqinligi, yuqori yangilanish tezligi, aniq ranglar
5.Nova tizimini qo'llab-quvvatlash, oddiy va qulay ishlash
6.Mahsulot moslashtirishni qo'llab-quvvatlaydi va teglar moslashtirilishi mumkin
7. Qulay tashish va tashish uchun parvoz qutisi qadoqlash
Maqsadimiz Xitoyning LED displey yechimlari bo'yicha yetakchi yetkazib beruvchisi bo'lishdir. Biz birgalikda ishlash va bozor tendentsiyalarini hisobga olgan holda LED texnologiyasini rivojlantirishga e'tibor qaratish uchun guruh yig'amiz. Bizniki, shuningdek, LED displeylarni yaxshilash bo'yicha ilg'or g'oyalarni ko'rib chiqadi.
Bizning maqsadimiz reklama, mahsulot haqida ma'lumot, tadbirlarni dasturlash va ko'ngilochar maqsadlarda foydalanish uchun yuqori sifatli, tejamkor LED displeylarni taklif qilish bilan birga vizual sifat texnologiyasini, LED displey ishlashini va foydalanuvchi tajribasini yaxshilashdir.
